    HG35-W600 ultrasonic welding machine Ultrasonic Knitted fabrics soldering machine

    Product Description

    HG35-W600 ultrasonic welding machine Ultrasonic Knitted fabrics soldering machine
    1. Ultrasonic systems allow to weld the edge of fabric in one single operation ! Our technology is based on the
    piezoelectric principle, to transform an electrical signal in mechanical vibration.

    2. These oscillations will be amplified by the booster and converter, thus creating a hammer. The converter conv-
    erts electricity into high frequency mechanical vibration. The active elements are usually piezoelectrics ceramics.
    The booster (optional) serves as an amplitude transformer. Amplitude magnification or reduction is achieved by
    certain design features or the geometrical shape of the booster.

    3. The sonotrode, or horn, is the active part of the ultrasonic unit. It is in contact with the fabric and acts as a hamm-
    er against the counter-tool. This system will enable to melt the fibers within the fabric by mechanical action only (h-
    ammering), enabling to obtain a very clean and flexible melting without any burning or color change. The sonotrode
    and counter-tool design will be adapted to the operation to be performed.

    4. The most simple way of welding thermoplastic materials is to use the ultrasonic manual welding device. This is
    particularly well suited for applications in prototype design, for processing of single products, small series and rep-
    airs. Regardless of caulking, swaging, staking, cutting, or spot welding, the HSG ultrasonic manual welding device
    iseasy to use, provides variable power rating, and can be equipped with all types of conventional sonotrodes.

    Sepecification

    Main Parameters

    System ModelHG20-W1000Power supply220V/50HZ
    Weight of handle0.9kgWelding time0.01s-99.99s
    Frequency20KHzStyleCylinder
    Max power1000WHorn MaterialTitanium/Aluminum
    Welding areaφ1-φ18Generator Size380*285*140mm
    Generator ModelFZ1000AGenerator Weight11KG

    Other Parameters

    Length of cable3 meterOriginChina
    Max length of cable10 meterBrandVTY
    ApplicationPlastic/fabricPackageCarton and wooden
    System Warranty3 YearsHorn Warranty3 months
    CustomizedYesCertificationCE
    Sample FreeNoShipping time20 days

    Process :


    Package :
